Chapter 6 PLC Link
108
6
Setting SYSMAC-C series
1. Set the RS-232C communication parameters (baud rate, data length, parity and
stop bit length) according to the BL-700’s settings.
2. Set the unit number according to the BL-700’s setting.
3. Set the command level to “Level 1, 2, 3”.
4. Set “1:1/1:N” to “1:N”.
5. Set “I/O port” to “RS-232C”.
6. Set “Trigger input” to “Internal”.
7. Set “Supply 5 V” to “Disable”.
8. Set “CTS” to “0 V (Normally ON).”
* The “I/O port”, “Trigger input”, “Supply 5 V” and “CTS” parameters may not be
provided depending on the type of link unit.
