KEYENCE BL-700 Series User Manual
Page 109
95
Chapter 5 Serial Communication
5
Function
Command being
Response
Description
Error
sent
code
Change
WCm02n
OK
m=0 to 3: Codes 1 to 4 00, 02,
Confirm
RCm02
02n
n=0: Disable
03, 04,
1: Enable
05, 07,
Change
WCm10n
OK
m=0 to 3: Codes 1 to 4 14
Confirm
WCm10
10n
n=0: Disable
1: Enable
Change
WCm11n
OK
m=0 to 3: Codes 1 to 4
Confirm
RCm11
11n
n=0: Disable
1: Enable
Change
WCm30n
OK
m=0 to 3: Codes 1 to 4
Confirm
RCm30
30n
n=0: Disable
1: Enable
Change
WCm31n
OK
m=0 to 3: Codes 1 to 4
Confirm
RCm31
31n
n=0: Lower case
1: Upper case
Change
WCm32n
OK
m=0 to 3: Codes 1 to 4
Confirm
RCm32
32n
n=0: Disable
1: Enable
Change
WCm33n
OK
m=0 to 3: Codes 1 to 4
Confirm
RCm33
33n
n=0: Disable
1: Enable
Change
WCm34n
OK
m=0 to 3: Codes 1 to 4 00, 02,
Confirm
RCm34
34n
n=0: Mudulus16
03, 04,
1: Modulus 11
05, 08,
2: Modulus 10/Wait 2 14
3: Modulus 10/Wait 3
4: 7 Check DR
5: Modulus 11-A
6: Modulus 10/
Wait 2-A
Change
WCm40n
OK
m=0 to 3: Codes 1 to 4 00, 02,
Confirm
RCm40
40n
n=0: Disable
03, 04,
1: Enable
05, 07,
Change
WCm41n
OK
m=0 to 3: Codes 1 to 4 14
Confirm
RCm41
41n
n=0: Disable
1: Enable
CODE39
Sending check
digit.
ITF
Inspection of check
digit (Modulus 10/
Wait 3)
ITF
Sending check
digit.
Codabar
Sending start/stop
character.
Codabar
Start/Stop
character type
Codabar
Inspection of check
digit
Codabar
Sending check digit
Codabar
Setting check digit
type
EAN/UPC (A•E)
Reading UPC-E
EAN/UPC (A•E)
Reading EAN 8
digits
