107
Chapter 6 PCL Link
6
Settings for KV-L2/KV mode*
1. Set the KV-L2’s communication mode to “KV mode”.
Set the BL-700’s communication mode to “KV”.
2. The KV mode must be always set to the following values:
• Baud rate : 9600 bps
• Data length: 8 bits
• Parity: Even
• Stop bit length: 1 bit
Set the RS-232C communication parameters of the BL-700 according to the
above settings.
3. Set the station number to “00”.
4. To use the KV-L2 port 2, set the port 2 selector switch to “RS-232C” or "RS-
422A".
5. No other parameters need to be set.
Note: KV-L2 is not available in Europe.
Settings for KV-L2/Display Interface mode
1. Set the KV-L2’s communication mode to “Display Interface” mode. To use link
mode, select “SYSMAC-C” for the BL-700’s setting.
2. Set the baud rate, data length, parity and stop bit length according to the RS-
232C communication parameters of the BL-700.
3. Set the station number to “00”.
4. To use the KV-L2 port 2, set the port 2 selector switch to “RS-232C” or “RS-
422A”.
5. No other parameters need to be set.
Setting MELSEC-A series
1. Set the RS-232C communication parameters (baud rate, data length, parity and
stop bit length) according to the BL-700’s settings.
2. Set the station number according to the BL-700’s setting.
3. Set the mode to “Protocol Type 4 ”.
4. Set the main channel to “RS-232C”.
5. Set “Checksum” to “Enable”.
6. Set “Write during running” to “Enable”.
7. Set “Selecting computer link/multi-drop” to “Computer link” (for the AJ71UC24
only).
