KEYENCE BL-700 Series - Manual (Page 36)

Chapter 2 Connection and Installation
2
22
SD+
SG
N-48
SD–
RD+
RD–
Link unit Twisted pair cable
1 RDB
RDA
SDB
SDA
FG
6
5
9
7
3 SG
D-sub 9-pin (male)
M2.6 screw
SD+
SG
N-48 Twisted pair cable
Communication
board
SD–
RD+
RD–
8 RDB
RDA
SDB
SDA
6
2
1
9 SG
D-sub 9-pin (male)
M2.6 screw
SD+
SG
N-42
SD–
RD+
RD–
PLC Twisted pair cable
8 RDB
RDA
SDB
SDA
RS
CS
6
2
1
4
9 SG
5
D-sub 9-pin (male)
M2.6 screw
■ Connecting SYSMAC-C series
Connecting with C200H-LK202 (-V1),
Connecting with C200HW-COM03/
C500-LK201-V1, COM06
C500-LK203,
C120-LK202-V1
■ Connecting SYSMAC-CV series
Connecting with CV-500-LK201,
CV500,
CV1000,
CVM1
Note: BL-U1 and KV-L2 are not available in Europe.
