2 – Server Administration NET SatisFAXtion 8.6 Manual 92
[Email_Sender_Address] [varchar](100)
Email address of the fax’s sender.
[Page_Count] [int]
Yet another page count.
[Forwarded_Message] [int]
Was the received fax forwarded.
[Receiver_Info] [varchar](25)
[Image_Transfer_Method] [varchar](50)
Code indicating the compression method used.
[Dial_Seconds] [int]
For outbound faxes, how many seconds elapsed from when the fax server
placed the call until when it was answered.
[V21_Frame_Error_Count] [int]
How many times V.21 signals had to be retransmitted due to lack of response
on the far side.
[ECM_Frame_Error_Count] [int]
How many times Error Correction was used to resend data corrupted due to line
impairment.
[RTP_Count] [int]
For non-ECM received faxes, how many times the fax server requested pages be
resent because 5–10% of the scan lines on that page were corrupt. Note that
the sending fax machine is not required to retransmit the page.
[RTN_Count] [int]
For non-ECM received faxes, how many times the fax server requested pages be
resent because 10% or more of the scan lines on that page were corrupt. Note
that the sending fax machine is not required to retransmit the page.
[DIS] [varchar](30)
Raw data from the far side’s DIS frame.
[NSF1] [varchar](128)
Raw data from the far side’s NSF1 frame.
[NSF2] [varchar](128)
Raw data from the far side’s NSF2 frame.
[Export_Location] [text]
The file name of the fax as saved by the Export module. Note that once the fax
is exported to disk, there is no further management of that file, so users or
other processes may have deleted, renamed or moved the file after the Export
process has completed.
2.8
Billing Codes
Billing codes provide additional information about faxes that gets logged in the
Reports database. There are two kinds of billing codes:
User Billing Codes: This is a code that is assigned to an account from the
Administration program. It is logged with every fax that user sends or receives.
