4 – Appendices
NET SatisFAXtion 8.6 Manual
199
30227 Unexpected V.34 end-of-transmission:
Remote fax sent an
unexpected V.34 modulation end of transmission indication. Error type:
RETRYABLE
.
30228 V.34 did not step down baud after four th PPR:
We received
the 4th PPR when sending a fax using V.34 modulation and the receiver did not
step down the baud rate. Error type:
RETRYABLE
.
30229 Timed out waiting for a command:
During phase B, the T1 timer
expired while waiting for commands from the sending fax machine. This timer is
35 seconds. Error type:
NON_RETRYABLE
.
30230 Timed out waiting for a command:
The 3 second T4 timer or the
6 second T2 timer has expired while waiting for a command from the remote
sender. Error type:
NON_RETRYABLE
.
30231 Invalid response after end-of-page:
After sending the end of
page command to the remote, the remote should have sent a MCF, PIP, RTP,
PIN, or RTN response. It sent something else. Error type:
RETRYABLE
.
30232 Send image timeout.
Error type:
RETRYABLE
.
30233 Send underrun.
Error type:
NON_RETRYABLE
.
30234 Insufficient memory. Error type:
NON_RETRYABLE
.
30235 Image mismatch. Error type:
NON_RETRYABLE
.
30236
SIP Invite sent 7 times with no response: The gateway did not
respond to SIP Invite requests. Check the configured gateway IP address, and
any firewall in between. Error type:
RETRYABLE
.
30237 Timeout waiting for invite final response:
Call was not
answered in the configured time period. Error type:
NO_ANSWER
.
30238 Unknown
SIP response code: Received nonstandard SIP code
from media gateway. See extended error code. Error type:
RETRYABLE
.
30239 Timeout waiting for reinvite to fax:
The call connected, but the
gateway failed to send a reinvite for T.38 either because there were no fax tones
detected on the remote side or because the gateway does not support T.38.
Error type:
RETRYABLE
.
30240 Timeout waiting for ACK of OK for reinvite to fax:
Media
gateway incompatibility or severe network issues. Error type:
RETRYABLE
.
30241
SIP response sent 7 times with no ACK: Media gateway
incompatibility or severe network issues. Error type:
RETRYABLE
.
30242 Reinvite OK received without
T.38 media: Media gateway
incompatibility. Error type:
RETRYABLE
.
30243
SIP bye received before fax was completed: The remote fax
device hung up before the fax was completed. The gateway also did not include
a Q.850 cause code for this disconnect, otherwise this would likely be 0x7210
Normal Call Clearing instead. Error type:
RETRYABLE
.
30244 Special Information Tone detected:
A SIT has been received.
This can include “number out of service” and other PSTN errors beyond the TDM
network (where Q.850 cause codes would be used instead). Error type:
NO_ANSWER
.
