In Ground Model 424x/424xLC

2

Automotive Dynamometer Installation Guide

C H A P T E R 4
Eddy Current Brake Installation

4-4

U

NPACKING

THE

E

DDY

C

URRENT

B

RAKE

1

Remove the top and sides of the crate.

2

Remove any hardware and parts boxes from the crate and verify the box contents
using the parts list.

3

Remove the uprights and cross members from the crate.

Figure 4-3: Remove the Crate Top

uprights and cross

members

crate top

remove boxes
