S P E C I F I C A T I O N S A N D O P E R A T I N G R E Q U I R E M E N T S
Dynamometer Specifications and Requirements
Version 7 In Ground Model 424x/424xLC 2 Automotive Dynamometer Installation Guide
1-9
F IRE S UPPRESSION
Always have adequate fire suppression or fire extinguishers in your dyno room.
F ORKLIFT R EQUIREMENTS
You will need to provide equipment capable of lifting 2,495 kg (5,500 lb.) to lift the
crated dyno and to lift the dyno off the crate and into position in your dyno room. You
will also need a pair of straps capable of supporting the uncrated dyno. Dynojet
recommends using single loop style straps. Use an approved strap lifting attachment
for the forklift to prevent strap slippage. To use lift straps with bare forks is not OSHA
compliant.
H YDRAULIC M OTOR
You will need to provide up to five quarts of AW-68 hydraulic fluid for the hydraulic
motor.
P HONE AND I NTERNET A CCESS
Dynojet recommends you have a phone close to the dyno to call for assistance in an
emergency. You may also wish to contact Dynojet to troubleshoot your dyno.
Internet access on your computer is desirable for contacting Dynojet and
downloading new information and updates.
T IE -D OWN S TRAPS
Dynojet recommends using tie-down straps for securing the car on the dyno. The
dyno comes with an automotive tie-down package.
