In Ground Model 424x/424xLC

2

Automotive Dynamometer Installation Guide

C H A P T E R 2
Unpacking and Inspecting the Dyno

2-4

forward pit cover, middle

P/N 21219117

riser foot assembly (4)

P/N 61319600

forward pit cover, left

P/N 21219118

dyno electronics

P/N 76100003N

runner mount, short (2)

P/N 21514801

bolt kit, 424 bridge

P/N 79110002

runner mount (2)

P/N 21514802

bolt kit, 4WD above ground

P/N 79110004

runner support (2)

P/N 21514803

bolt kit, 3/8-16 x 5", black

oxide

P/N 79110006

forward pit cover spacer

P/N 21519140

ground hook kit (10)

P/N 79190001

see list of parts below

runner extension, left

P/N 21519811

banner, dynojet (2)

P/N D706

runner extension, right

P/N 21519812

inductive secondary

pickup (2)

P/N DE100-109S

part

description

part

description
