In Ground Model 424x/424xLC

2

Automotive Dynamometer Installation Guide

C-1

A

P P E N D I X

C

S

TATIONARY

D

YNO

U

PGRADE

This appendix contains instructions for upgrading an existing stationary dyno to be
used with the 4WD dyno including relocating the deck, adding the lift kit, and
adjusting the air fittings. To ensure safety and accuracy in the procedures, perform the
procedures as they are described.
This Appendix is divided into the following categories:
• Lift Kit Installation, on page C-2
• Air Fittings Upgrade, on page C-3

This manual is related to the following products:
