4 W D D Y N O I N S T A L L A T I O N
Bridge Installation—Stationary Dyno
Version 7 In Ground Model 424x/424xLC 2 Automotive Dynamometer Installation Guide
3-33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BRIDGE INSTALLATION—STATIONARY DYNO
Use the following instructions to install the drum guards, runner mounts and
supports, runner assemblies, and the bridge cover.
You will need the following parts:
• 21214703 Runner Clamp Plate (2)
• 21214704 Runner Slide (2)
• 21216103 Drum Guard, Rear
• 21219113 Drum Guard, Left, Stationary
• 21219114 Drum Guard, Front, Stationary
• 21219115 Drum Guard, Right, Stationary
• 21219511 Bridge Cover, Stationary Dyno
• 21514802 Runner Mount (z-shaped) (2)
• 21514803 Runner Support (2)
• 21519811 Runner Extension, Left
• 21519812 Runner Extension, Right
• 36468100 Nut, 1/4-20, Nylock (4)
• 36562070 Bolt, 1/4-20 x 1.25", Hex (16)
• 36562470 Bolt, 1/4-20 x 1.5”, Hex (4)
• 36580434 Bolt, 3/8-16 x 1/2", Button-Head, Flange, Allen (4)
• 36582034 Bolt, 3/8-16 x 1.25", Button-Head, Flange, Allen (8)
• 36582471 Bolt, 3/8-16 x 1.5", Flange-Hex (6)
• 36588071 Bolt, 3/8-16 x 5", Black Oxide (16)
• 36701100 Nut, 1/2-13, Hex (8)
• 36800000 Bolt, 1/2-13 x 3", Hex (8)
• 36912100 Washer, 1/4", Splitlock, Steel (16)
• 36923100 Washer, 3/8", Hardened, Flat, Steel (26)
• 36932100 Washer, 3/8", Splitlock, Steel (16)
• 36942100 Washer, 1/2", Splitlock, Steel (8)
• 37513200 Anchor, Redhead, 3/8" (10)
• 37518200 Redhead Anchor Installation Tool
• 61119810 Runner Extension Support Leg (2)
• 61314500 Runner Support Assembly (4)
• 61319500 Runner Assembly (16)
• DM150-009-003 Washer, 1/4", Flat (4)
• DM150-011-004 Nut, 3/8-16, Hex (16)
• DM150-019-012 Bolt, 3/8-16 x 1", Hex (10)
