S T A T I O N A R Y D Y N O I N S T A L L A T I O N
Unpacking and Inspecting the Dyno
Version 7 In Ground Model 424x/424xLC 2 Automotive Dynamometer Installation Guide
2-5
chock (4)
P/N 2A092
inductive primary pickup
clip
P/N DE100-110L
nut, 1/4-20, nylock (4)
P/N 36468100
bolt, 3/8-16 x 1", hex (6)
P/N DM150-019-012
bolt, 1/4-20 x 1.5", hex (4)
P/N 36562470
The following parts are included in the Retarder Upgrade P/N 77010005:
theta controller mounting
bracket (2)
P/N 21616205
washer, 1/2", flat (4)
P/N 36943102
splined shaft
P/N 22117130
driveline assembly
P/N 62240130
bearing, flange
P/N 32355056
torque module
P/N 66104001
nut, 3/8-16, nylock (4)
P/N 36488100
theta controller (2)
P/N 66411004
screw, 8-32 x 3/8", pan-head,
sems, phil (8)
P/N 36540647
load cell assembly
P/N 76950505
part description part description
