B - power requirements and installation – Dynojet 424x: Installation Guide User Manual
Page 129

In Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
B-1
A
P P E N D I X
B
P
OWER
R
EQUIREMENTS
AND
I
NSTALLATION
This appendix contains power requirements and installation instructions for the eddy
current brake. To ensure safety and accuracy in the procedures, perform the
procedures as they are described. Be sure to read and understand the warnings
included in this appendix.
This Appendix is divided into the following categories:
• North America, Japan, and Locations Using 60 Hz Power, on page B-2
• Excluding North America and Japan, on page B-5
