D - bridge extension assembly – Dynojet 424x: Installation Guide User Manual
Page 141
In Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
D-1
A
P P E N D I X
D
B
RIDGE
E
XTENSION
A
SSEMBLY
This appendix contains instructions for installing the bridge extension assembly to
the stationary dyno. To ensure safety and accuracy in the procedures, perform the
procedures as they are described.
