Figure 3-8 – Dynojet 424x: Installation Guide User Manual
Page 50
In Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
C H A P T E R 3
Cable Routing
3-14
Figure 3-8: Routing the Cables—Without the Eddy Current Brakes
DRY AIR IN
100-140 PSI
AD390
E
D
C
dyno electronics
stationary
dyno
4WD dyno
first cable
track
F
power supply
dyno movement
pendant
power supply for
dyno electronics
breakout
board
second
cable track
A
H
G
B
I
