In Ground Model 424x/424xLC

2

Automotive Dynamometer Installation Guide

C H A P T E R 1
Dynamometer Specifications and Requirements

1-4

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DYNAMOMETER SPECIFICATIONS AND REQUIREMENTS

The following specifications and requirements will help you set up your dyno area
and verify you have the requirements necessary to operate your dyno safely.

C

HASSIS

S

PECIFICATIONS

description

specifications

Length

of frame

218.44 cm (86.00 in.)

of frame with eddy current brake

321.23 cm (126.47 in.)

including eddy current brake and
covers

345.44 cm (136.00 in.)

Height

to top of frame

58.42 cm (23.00 in.)

to top of frame with feet/track
assembly

72.07 cm (28.375 in.)

Width

of frame

73.66 cm (29.00 in.)

including cradle assembly

130.18 cm (51.25 in.)

including air brake

93.83 cm (36.94 in.)

both frames, bridge, covers—full out

584.20 cm (230.00 in.)

both frames, bridge, covers—full out
with extension kit

609.60 cm (240.00 in.)

both frames, bridge, covers—full in

469.90 cm (185.00 in.)

both frames, bridge, covers—full in
with extension kit

495.30 cm (195.00 in.)

Track Assembly

Length

234.32 cm (92.25 in.)

Width

218.44 cm (86.00 in.)

Weight

stationary crated dyno

2,114 kg (4,660 lb.)

4WD crated dyno

2,495 kg (5,500 lb.)

Drum

diameter

60.96 cm (24.00 in.)

width

205.74 cm (81.00 in.)

Frame

structural steel channel and angle

Maximum Speed

322 KPH (200 MPH)

Maximum Axle Weight

1361 kg (3000 lb.)

Remote Switches

remote software control
