Model 424 stationary and 4wd dynamometer – Dynojet 424x: Installation Guide User Manual
Page 20

In Ground Model 424x/424xLC
2
Automotive Dynamometer Installation Guide
C H A P T E R 1
Model 424 Stationary and 4WD Dynamometer
1-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MODEL 424 STATIONARY AND 4WD DYNAMOMETER
Figure 1-4: Model 424 Stationary and 4WD Dynamometer
AD376
Drum
precision balanced
and knurled
Track Assembly
Dyno Movement
Hydraulic Motor
Cradle Assembly
4WD Dyno
Stationary Dyno
Eddy Current Brake
with theta controller
Spring Applied Air
Brake
Breakout Board
Spring Applied Air
Brake
