Dynojet 424x: Installation Guide - Manual (Page 30)

In Ground Model 424x/424xLC 2 Automotive Dynamometer Installation Guide
C H A P T E R 2
Unpacking and Inspecting the Dyno
2-6
nut, 1/2-13, nylock, hex (4)
P/N 36708100
temperature sensor
P/N 76955001
bolt, 1/2-13 x 1.5", flange,
hex (6)
P/N 36801080
bolt, 3/8-16 x 1", hex (12)
P/N DM150-019-012
washer, 3/8", flat (12)
P/N 36923100
The following parts are included in the Retarder Cover Kit P/N 78119004:
calibration cover (2)
P/N 21217513
support leg
P/N 61319507
foot, retarder cover (6)
P/N 21919101
pit cover, retarder (2)
P/N 61329400
screw, 1/4-20 x 5/8", pan-
head, torx (12)
P/N 36561045
washer, 3/8", flat (8)
P/N DM150-011-002
bolt, 3/8-16 x 1.5", hex (8)
P/N 36582477
bolt, 3/8-16 x 1", hex (8)
P/N DM150-019-012
anchor, redhead, 3/8" (8)
P/N 37513200
part description part description
