Sensor Installation and Connection 3-37
2
Extension cables can be ordered to specific lengths up to 91 meters. Note the
desired length (meters converted to feet) in the -xxx-- portion of the part number.
Standard lengths are 3.0m (10 ft.), 7.6m (25 ft.), 15.2m (50 ft.), 22.8m (75 ft.),
30.5m (100 ft.), 38.1m (125 ft.), 45.7m (150 ft.), and 61.0m (200 ft.). All other
lengths must be custom ordered.
3
Communication cables can be ordered in 3-, 26-, 30-, or 41-meter (10-, 85-, 100-,
or 135-ft.) lengths. Other cable lengths up to 91 meters (300 ft.) are also available
by request. Indicate the desired length in feet in the -xx- portion of the part number.
Gathering the Tools and Equipment
Gather the following tools for the installation:
Battery-powered hammer drill with assorted bits – including
the following at a minimum:
6-mm x 150-mm masonry bit
10-mm x 100-mm (minimum length) masonry bit
8-mm and 10-mm carbide-tipped bits
1- to 2-kg hammer
Rubber mallet
500- to 1000-mm carpenter’s level
Metric nut driver or socket set
Metric wrenches
Screwdrivers (flathead and Phillips head of assorted sizes)
Threads tap compatible with the thread spec on the monitor
mounting stud
Diagonal wire cutters
Folding carpenter’s rule with a brass slide
Mastic tape (p/n 507193) or rubber coaxial stretch tape
