6-76 IETG FlowHawk Manual
Pressure Diagnostics dialog showing the results for the Pressure 1 device
following sensor firing
3. Verify the accuracy of the pressure depth and temperature
readings, and edit the configuration parameters as necessary.
4. Select the Store button to save any changes made in the device
parameters to the LIF in the database.
5. Select the Close button to exit the Pressure Diagnostics dialog
and return to the Monitor Diagnostics dialog.
Velocity Diagnostics
This section provides instructions for running diagnostics on the
peak, surface, and surcharge velocity sensors found in the Peak
Combo Sensor (PC), Surface Combo Sensor (SC), and Slimline
Peak Combo Sensor (PCS) once connected to the monitor through
the Monitor Diagnostics dialog. Run diagnostics on all of the
velocity sensors in the following way:
