4-28 IETG FlowHawk Manual
Wiring the Communication Cable
Once the communication cable has been installed and at least 1016
millimeters (40 in) of communication cable extends from the
ground, wire the communication cable to the EMU and install the
external power kit:
1. Unscrew the 4 large plastic screws with the Phillips head
screwdriver and remove the cover to the EMU. Carefully set
the cover aside to avoid damage and prevent dirt from
contacting the cover gasket.
Inside of EMU with front cover removed
2. Lay the EMU down next to the power source location, and
loosen the nut on the communication cable entry fitting. If the
fitting is snapped closed, use a small flat-blade screwdriver to
gently pry open the ears of the fitting.
