3-10 IETG FlowHawk Manual
Quantity
Description
Part Number
As needed
10mm stainless washer
15
5mm x 300mm cable tie
25
2mm x 100mm cable tie
15
4mm x 200mm cable tie
15
7mm x 400mm anchor cable tie
1
457-mm stainless steel crank handle
I10–0012
1
IS pressure depth transducers (indicated by -xx- in the part number) are available
in Peak Combo Sensors, Surface Combo Sensors, and Ultrasonic Depth Sensor with
a Pressure Option in 0 - 0.34 Bar (0 - 5 psi) and 0 – 1.03 Bar (0 - 15 psi) pressure
ranges. The Peak Combo Sensor also offers a 0 - 2.07 Bar (0 - 30 psi) option.
Example: a Peak Combo Sensor with a 0 - 1.03 Bar pressure transducer would be
specified in psi: 8K-CS1-D1-15-35.
2
Extension cables can be ordered to specific lengths up to 91 meters. Note the
desired length (meters converted to feet) in the –xxx-- portion of the part number.
Standard lengths are 3.0m (10 ft.), 7.6m (25 ft.), 15.2m (50 ft.), 22.8m (75 ft.),
30.5m (100 ft.), 38.1m (125 ft.), 45.7m (150 ft.), and 61.0m (200 ft.). All other
lengths must be custom ordered.
3
Communication cables can be ordered in 3-, 26-, 30-, or 41-meter (10-, 85-, 100-,
or 135-ft.) lengths. Other cable lengths up to 91m (300 ft.) are also available by
request. Indicate the desired length in feet in the -xx- portion of the part number.
Gathering Tools and Equipment
Gather the following tools for the installation:
Battery-powered hammer drill with assorted bits – including
the following at a minimum:
6-mm x 150-mm masonry bit
10-mm x 100-mm (minimum length) masonry bit
8-mm carbide-tipped bit
Heavy 1.5-Kg hammer
Rubber mallet
Carpenter’s level (approximately 610 mm in length)
