4-30
IETG FlowHawk Manual
4. Terminate the 12 wires into the orange connector, using the 3-
mm (1/8-in) flat head screwdriver, as shown on the label
affixed to the inside cover of EMU box. Make sure all screws
are tight.
Terminal
Wire Color
Gauge Wire
1
Yellow
22
2
Blue (small)
22
3
Black (small)
22
4
White
22
5
Red (small)
22
6
Green (small)
22
7
Brown
22
8
Orange
22
9
Red (large)
18
10
Blue (large)
18
11
Black (large)
18
12
Green (large)
and bare shield
drain wire
18 (green)/
22 (drain
wire)
Note: The wires can become loose while moving the
cable. Therefore, after terminating the wires, verify once
again that each wire is secure.
5. Plug the orange connector into the corresponding port on the
black Communication Interface/Barrier Box, and then pull back
the excess cable from the outside of the EMU.
