Specifications A-13
External Modem Unit (p/n 3800-0148)
The EMU (external modem unit) supports the externally-powered
FlowHawk monitor.
Enclosure Rectangular UL-Recognized NEMA 4X/6P
composite enclosure with stainless steel
hardware
Dimensions 457 millimeters (18 in) high x 152 millimeters (6
in) wide x 191 millimeters (7.5 in) deep
Weight 5.44 kilograms (12 lbs)
Operating
Temperature
-18 ° to 60° C (0° to 140° F)
External Power Requires an external DC power source providing
a minimum of 12 volts at 1 amp
Wireless Modem Enfora Model GSM1308-50 Quad-band
GSM/GPRS (850/900/1850/1900 MHz)
Connections Sealed NEMA 4X right-angle cable grip fitting for
communication cable
Communication
Cable
Available lengths: 26.0, 30.5, and 41.1 meters
(85, 100, and 135 ft)
Jacket: 8-mm (0.318-inch) OD heavy gauge
polyurethane direct burial
Conductors: 8-20 gauge and 4-18 gauge
Connectors: Factory-fitted, potted (monitor end);
field terminated strip connection (EMU end)
FCC ID FCC ID MIVGSM0308
Antenna Smarteq ™ mini-wing (SMA/TNC)
Protocol TCP/IP
Addressing Fixed address via AT&T custom APN
