ADS Environmental Services IETG FlowHawk QR 775012 A4 User Manual
Page 306

8-22 IETG FlowHawk Manual
3. Remove the electrical tape sealing the seam between the cover
and top of the GSM module enclosure.
4. Loosen the four plastic Phillips head screws from the clear top
of the module, and then remove the top.
5. (applicable only when replacing the desiccant) Replace the
desiccant in the following way:
Remove the existing desiccant pack from the module and
discard.
Inspect the inside of the module for any moisture. If
moisture is present, remove it with a clean, dry paper
towel.
Insert a new desiccant pack into the module.
Inserting the desiccant into an open GSM module
6. (applicable only when replacing the SIM card) Replace the
SIM card in the following way:
Inspect the inside of the module for any moisture. If
moisture is present, remove it with a clean, dry paper
towel.
Slide back the clip on the SIM card carrier to unlock the
carrier.
Place desiccant here
