Communication 4-41
Installing the EMUX
Installing the wireless EMUX primarily involves installing the SIM
card in the EMUX, connecting the communication cable to the
EMUX, and mounting the EMUX near the RTU and/or external
power source.
Gathering Tools and Equipment
Obtain the following items before initiating installation:
 Medium (No. 2) Phillips head screwdriver
 13-mm (1/2-in) flat head screwdriver
 3-mm (1/8-in) flat head screwdriver (to fit the orange
communication cable terminal block)
 Wire strippers (with holes to strip 16-, 18-, and 20-gauge wires)
 Small, sharp side cutters (Do not use the big cable tie trimmers
used for ring/monitor installations!)
 Vinyl electrical tape (not stretch tape)
Installing the SIM Card
Install the SIM card in the EMUX in the following way:
1. Record the IP address of the SIM card. The address should be
printed directly on the card or on a label affixed to the card.
2. Loosen and remove the two screws from the front cover of the
EMUX, and then remove the cover.
