3-12 IETG FlowHawk Manual
Ring stabilizer with spreader mechanism screw
2. Slide the open end of the ring (end without the welded metal
band) through the flanges in the ring stabilizer, making sure
the flanges face the outside of the ring and the spreader
mechanism screw faces the inside of the ring.
Sliding the ring stabilizer onto the ring
3. Slide the ring stabilizer all the way around the ring until it is
about 102 mm from the welded metal band at the other end of
the ring.
