Configure and Start Up the Kinetix 350 Drive System Chapter 5

Configure the Kinetix 350
Drive Ethernet IP Address

This section offers guidance on configuring your Ethernet connection to the
Kinetix 350 drive.

Ethernet Connection

Configuration, programming, and diagnostics of the Kinetix 350 drive are
performed over the standard 10/100 Mbps Ethernet communication port by
using the Studio 5000 Logix Designer application.

The Kinetix 350 drive and your personal computer must be configured to
operate on the same Ethernet network. The IP addresses of the Kinetix 350 drive,
the personal computer, or both drive and personal computer can require
configuring to enable Ethernet communication between the two devices.

Kinetix 350 Drive Ethernet Port Configuration

The IP address of the Kinetix 350 drive is composed of four sub-octets that are
separated by three dots to conform to the Class C Subnet structure. Each sub-
octet can be configured with number between 1 and 254. As shipped from the
factory the default IP address of a drive is 192.168.124.200.

There are two methods of changing the current IP address. An address can be
assigned to the drive automatically (dynamic IP address) when the drive is
connected to a DHCP (Dynamic Host Configuration Protocol) enabled server,
or you can manually assign an IP address to the drive (static IP address). Both
methods of configuring the drive’s IP address are shown here.

Obtain the Kinetix 350 Drives’ Current Ethernet Settings

The current Ethernet setting and IP address of the Kinetix 350 drive can be

obtained from the drive display and keypad. Press

on the display and use

to access parameters IP_1, IP_2, IP_3, and IP_4. Each of these

parameters contain one sub-octet of the full IP address, for example in the case of
the drive default (factory set) address parameters:

IP_1 = 192

IP_2 = 168

IP_3 = 124

IP_4 = 200

IMPORTANT

Any changes made to the Ethernet communication settings on the
Kinetix 350 drive do not take effect until the drive is powered off and
powered on again. Until the power is cycled the drive continues to use its
previous settings.
