Rockwell Automation Publication 2097-UM002C-EN-P - December 2013

139

Interconnect Diagrams Appendix A

Motor Brake Currents

Use these coil current values to size the interposing relay required for your
application. Refer to the interconnect diagram for your Kinetix 350 drive/motor
beginning on

for typical motor brake circuitry.

Table 66 - Motor Brake Coil Currents

Compatible Brake Motors/Actuators

(1)

(1) Use of the variable x indicates this specification applies to 230V and 460V motors.

Coil Current

MPL-x1510, MPL-x1520, MPL-x1530

0.43…0.53 A

MPL-x210, MPL-x220, MPL-x230

0.46…0.56 A

MPL/MPF-x310, MPL/MPF-x320, MPL/MPF-x330

0.45…0.55 A

MPM-x115

MPS-x330

MPL-x420, MPL-x430, MPL-x4520, MPL-x4530, MPL-x4540,
MPL-B4560

0.576…0.704 A

MPM-x130

MPF-x430, MPF-x4530, MPF-x4540

MPS-x4540

TLY-A110T, TLY-A120T, and TLY-A130T

0.18…0.22 A

TLY-A220T and TLY-A230T

0.333…0.407 A

TLY-A2530P, TLY-A2540P, and TLY-A310M

0.351…0.429 A
