Rockwell Automation Publication 2097-UM002A-EN-P - December 2013 33
Install the Kinetix 350 Drive System Chapter 2
Mount Your Kinetix 350 Drive This procedure assumes you have prepared your panel and understand how to
bond your system. For installation instructions regarding other equipment and
accessories, refer to the instructions that came with those products.
Follow these steps to mount your Kinetix 350 drive.
1. Lay out the position for the Kinetix 350 drive and accessories in the
enclosure.
Refer to Establishing Noise Zones on page 28 for panel layout
recommendations. Mounting hole dimensions for the Kinetix 350 drive
are shown in Kinetix Servo Drives Specifications Technical Data,
publication number
GMC-TD003 .
2. Attach the Kinetix 350 drive to the cabinet, first by using the upper
mounting slots of the drive and then the lower.
The recommended mounting hardware is M4 (#6-32) steel machine
screws torqued to 1.1 N•m (9.8 lb•in). Observe bonding techniques as
described in
Bonding Drives on page 25 .
3. Tighten all mounting fasteners.
ATTENTION: This drive contains electrostatic discharge (ESD) sensitive parts
and assemblies. You are required to follow static control precautions when you
install, test, service, or repair this assembly. If you do not follow ESD control
procedures, components can be damaged. If you are not familiar with static
control procedures, refer to Guarding Against Electrostatic Damage, publication
8000-4.5.2 , or any other applicable ESD Protection Handbook.
IMPORTANT To improve the bond between the Kinetix 350 drive and subpanel,
construct your subpanel out of zinc plated (paint-free) steel.
