Troubleshooting
Chapter 2
Alarm Descriptions
Table 4 - Alarm Descriptions and Actions
Alarm
No
.
Ty
pe
(1)
Description
AdjVoltRef Cflct
33
1 Invalid adjustable voltage reference selection conflict.
Analog In Loss
5
1 An analog input is configured for “Alarm” on signal loss and signal loss has occurred.
Bipolar Conflict
20
2 Parameter 190 [Direction Mode] is set to “Bipolar” or “Reverse Dis” and one or more of the
following digital input functions is configured: “Fwd/Reverse,”
“Run Forward,” “Run Reverse,” “Jog Forward” or “Jog Reverse.”
Brake Slipped
32
2 Encoder movement has exceeded the level in [BrkSlipCount] after the brake was set.
Brake Slipping
16
2 Brake slip procedure is in progress.
Decel Inhibt
10
1 Drive is being inhibited from decelerating.
Dig In ConflictA
17
2 Digital input functions are in conflict. Combinations marked with a “ ” will cause an
alarm.
Dig In ConflictB
18
2 A digital Start input has been configured without a Stop input or other functions are in
conflict. Combinations that conflict are marked with a “ ” and will cause an alarm.
Dig In ConflictC
19
2 More than one physical input has been configured to the same input function. Multiple
configurations are not allowed for the following input functions.
Forward/Reverse
Run Reverse
Bus Regulation Mode B
Speed Select 1
Jog Forward
Acc2 / Dec2
Speed Select 2
Jog Reverse
Accel 2
Speed Select 3
Run
Decel 2
Run Forward
Stop Mode B
DPI Port1 Loss
38
1 The HIM connected to DPI Port 1-3 stopped communicating to the drive. Check the HIM
connection.
DPI Port2 Loss
39
1
DPI Port3 Loss
40
1
Drive OL Level 1
8
1 The calculated IGBT temperature requires a reduction in PWM frequency. If [Drive OL Mode]
is disabled and the load is not reduced, an overload fault will eventually occur.
Drive OL Level 2
9
1 The calculated IGBT temperature requires a reduction in Current Limit. If [Drive OL Mode] is
disabled and the load is not reduced, an overload fault will eventually occur.
FluxAmpsRef
Rang
26
2 The calculated or measured Flux Amps value is not within the expected range. Verify motor
data and rerun motor tests.
Ground Warn
15
1 Ground current has exceeded the level set in [Gnd Warn Level].
v6
Acc2/Dec2
Accel 2 Decel 2 Jog 1/2
Jog Fwd
Jog Rev
Fwd/Rev
Acc2/Dec2
Accel 2
Decel 2
Jog 1/2
Jog Fwd
Jog Rev
Fwd/Rev
Start
Stop-
CF
Run Run Fwd Run Rev
Jog
1/2
Jog Fwd Jog Rev
Fwd/
Rev
Start
Stop-CF
Run
Run Fwd
Run Rev
Jog 1/2
Jog Fwd
Jog Rev
Fwd/Rev
