p 648 [Gearbox Limit]
Sets the gearbox torque limit. This value is used
in determining the [Pos Torque Limit] & [Neg
Torque Limit].
Default:
Min/Max:
Units:
100.0%
0.0/200.0%
0.1%
Adju
st
V
ol
tage
650 [Adj Volt Phase]
“1 Phase” (0) - Select to operate single phase
loads connected to the U & V phases. Not
designed to operate single phase motors.
“3 Phase” (1) - Select to operate three phase
loads.
Default:
Options:
1
0
1
“3 Phase”
“1 Phase”
“3 Phase”
651 [Adj Volt Select]
Selects the source of the voltage reference to the
drive.
Default:
Options:
2
0
1
2
3-6
7-8
9
10
11-17
18-22
“Analog In 2”
“Reserved”
“Analog In 1”
“Analog In 2”
“Reserved”
“Not Used
“MOP Level”
“Reserved”
“Preset Volt1-7”
“DPI Port 1-5”
652 [Adj Volt Ref Hi]
Scales the upper value of the [Adj Volt Select]
selection when the source is an analog input.
Default:
Min/Max:
Units:
100.0%
–/+100.0% of Drive Rated Volts
0.1%
653 [Adj Volt Ref Lo]
Scales the lower value of the [Adj Volt Select]
selection when the source is an analog input.
Default:
Min/Max:
Units:
0.0%
–/+100.0% of Drive Rated Volts
0.1%
654
655
656
657
658
659
660
[Adj Volt Preset1]
[Adj Volt Preset2]
[Adj Volt Preset3]
[Adj Volt Preset4]
[Adj Volt Preset5]
[Adj Volt Preset6]
[Adj Volt Preset7]
Provides an internal fixed voltage command
value that is available as a selection for [Adj Volt
Select].
Default:
Min/Max:
Units:
0.0 VAC
0.0/Drive Rated Volts
0.1 VAC
661 [Min Adj Voltage]
Sets the low limit for the voltage reference when
[Motor Cntrl Sel] is set to “Adj Voltage.”
Default:
Min/Max:
Units:
0.0 VAC
0.0/Drive Rated Volts
0.1 VAC
662 [Adj Volt Command]
Displays the voltage value of the reference
specified in [Adj Volt Select].
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated Volts
0.1 VAC
663 [MOP Adj VoltRate]
Sets the rate for the MOP.
Default:
Min/Max:
Units:
1.0 V/s
0.1/100.0 V/s
0.1 V/s
669 [Adj Volt TrimSel]
Selects the source of the voltage trim that is
added to or subtracted from the voltage
reference.
Default:
Options:
2
0
1
2
3-6
7-8
9
10
11-17
18-22
“Analog In 2”
“Reserved”
“Analog In 1”
“Analog In 2”
“Reserved”
“Not Used
“MOP Level”
“Reserved”
“Preset Volt1-7”
“DPI Port 1-5”
