284 [MOP Mask]
Controls which adapters can issue MOP
commands to the drive.
See
…
285 [Local Mask]
Controls which adapters are allowed to take
exclusive control of drive logic commands (except
stop). Exclusive “local” control can only be taken
while the drive is stopped.
See
…
288 [Stop Owner]
Adapters that are presently issuing a valid stop command.
Read Only
…
289 [Start Owner]
Adapters that are presently issuing a valid start
command.
See
…
290 [Jog Owner]
Adapters that are presently issuing a valid jog
command.
See
…
291 [Direction Owner]
Adapter that currently has exclusive control of
direction changes.
See
…
292 [Reference Owner]
Adapter that has the exclusive control of the
command frequency source selection.
See
…
293 [Accel Owner]
Adapter that has exclusive control of selecting
[Accel Time 1, 2].
See
…
294 [Decel Owner]
Adapter that has exclusive control of selecting
[Decel Time 1, 2].
See
…
295 [Fault Clr Owner]
Adapter that is presently clearing a fault.
See
…
296 [MOP Owner]
Adapters that are currently issuing increases or
decreases in MOP command frequency.
See
…
297 [Local Owner]
Adapter that has requested exclusive control of
all drive logic functions. If an adapter is in local
lockout, all other functions (except stop) on all
other adapters are locked out and non-
functional. Local control can only be obtained
when the drive is not running.
See
…
Fil
e
Gr
oup
No
.
Parameter Name & Description
See
page 16
for symbol descriptions
Values
Rela
ted
0
0
0
1
0
0
x
x
x
x
x
x
x
x
x
x
10
0
1
2
3
4
5
6
7
8
9
11
12
13
14
15
1 = Issuing Command
0 = No Command
x = Reserved
