Rockwell Automation Publication 20B-UM002G-EN-P - July 2014 105
HIM Overview Appendix B
Diagnostics Menu
When a fault trips the drive, use this menu to access detailed data about the drive.
Parameter Menu
Refer to Viewing and Editing Parameters on page 106 .
The drive is initially set to Basic Parameter View. To view all parameters, set
parameter 196 [Param Access Lvl] to option 1 “Advanced.” To view Engineering
parameters (refer to the PowerFlex Reference Manual, publication PFLEX-
RM002 for details) select option 2 “Reserved.” Parameter 196 is not affected by
the Reset to Defaults.
Device Select Menu
Use this menu to access parameters in connected peripheral devices.
Memory Storage Menu
Drive data can be saved to, or recalled from, User and HIM sets.
User sets are files stored in permanent nonvolatile drive memory.
HIM sets are files stored in permanent nonvolatile HIM memory.
Start Up Menu
See Installation Instructions.
Preferences Menu
The HIM and drive have features that you can customize.
Option Description
Alarms View alarm queue and clear alarms.
Faults View fault queue or fault information, clear faults or reset drive.
Status Info View parameters that display status information about the drive.
Device Version View the firmware version and hardware series of components.
HIM Version View the firmware version and hardware series of the HIM.
Option Description
Changed Parameters changed for default.
Option Description
HIM Copycat
Device -> HIM
Device <- HIM Save data to a HIM set, load data from a HIM set to active drive memory
or delete a HIM set.
Device User Sets Save data to a User set, load data from a User set to active drive
memory or name a User set.
Reset To Defaults Restore the drive to its factory-default settings.
