Programming and Parameters
Chapter 1
SPEED C
OMMAND
Speed Re
fe
re
nces
090 [Speed Ref A Sel]
Selects the source of the speed reference to the
drive unless [Speed Ref B Sel] or [Preset Speed 1-
7] is selected.
(1)
See
(2)
If selected, HIM manual control is not allowed.
(3)
Minimum 64 PPR required.
Default:
Options:
2
1
2
3-6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23-24
25
26
27
28
29
30
“Analog In 2”
“Analog In 1”
“Analog In 2”
“Reserved”
“Pulse In”
(3)
“Encoder”
“MOP Level”
“Reserved”
“Preset Spd1”
“Preset Spd2”
“Preset Spd3”
“Preset Spd4”
“Preset Spd5”
“Preset Spd6”
“Preset Spd7”
“DPI Port 1”
(1) (2)
“DPI Port 2”
(1)
“DPI Port 3”
(1)
“DPI Port 4”
(1)
“DPI Port 5”
(1)
“Reserved”
“Scale Block1”
“Scale Block2”
“Scale Block3”
“Scale Block4”
“Reserved”
“HighRes Ref”
…
…
…
…
…
091 [Speed Ref A Hi]
Scales the upper value of the [Speed Ref A Sel]
selection when the source is an analog input.
Default:
Min/Max:
Units:
[Maximum Speed]
–/+[Maximum Speed]
0.1 Hz
0.01 RPM
092 [Speed Ref A Lo]
Scales the lower value of the [Speed Ref A Sel]
selection when the source is an analog input.
Default:
Min/Max:
Units:
0.0
–/+[Maximum Speed]
0.1 Hz
0.01 RPM
093 [Speed Ref B Sel]
See
Default:
Options:
11
“Preset Spd1”
See
094 [Speed Ref B Hi]
Scales the upper value of the [Speed Ref B Sel]
selection when the source is an analog input.
Default:
Min/Max:
Units:
[Maximum Speed]
–/+[Maximum Speed]
0.1 Hz
0.01 RPM
095 [Speed Ref B Lo]
Scales the lower value of the [Speed Ref B Sel]
selection when the source is an analog input.
Default:
Min/Max:
Units:
0.0
–/+[Maximum Speed]
0.1 Hz
0.01 RPM
Fil
e
Gr
oup
No
.
Parameter Name & Description
See
page 16
for symbol descriptions
Values
