How parameters are organized, Numbered list view – Rockwell Automation 20B PowerFlex 700 AC Drives Vector Control (v4.001 and up) User Manual
Page 17

Rockwell Automation Publication 20B-UM002G-EN-P - July 2014
17
Programming and Parameters
Chapter 1
How Parameters are
Organized
The LCD HIM displays parameters in a File-Group-Parameter or Numbered
List view order. To switch display mode, access the Main Menu, press ALT, then
Sel while cursor is on the parameter selection. In addition, using
, the user has the option to display the full
parameter set (Advanced),
commonly used parameters (Basic) or diagnostic/advanced tuning parameters
(Reserved).
To simplify programming, the displayed parameters will change according to the
selection made with
. For example, if “FVC Vector” is selected,
the parameters associated solely with other operations such as Volts per Hertz or
Sensorless Vector will be hidden. Refer to pages
and
.
File-Group-Parameter Order
This simplifies programming by grouping parameters that are used for similar
functions. The parameters are organized into files. Each file is divided into
groups, and each parameter is an element in a group. By default, the LCD HIM
displays parameters by File-Group-Parameter view.
Numbered List View
All parameters are in numerical order.
