Rockwell Automation Publication 20B-UM002G-EN-P - July 2014 139
Application Notes Appendix C
Definitions
• Wake - A start command generated when the analog input value remains
above [Wake Level] (or below when Invert mode is active) for a time
greater than [Wake Time].
• Sleep - A Stop command generated when the analog input value remains
below [Sleep Level] (or above when Invert mode is active) for a time
greater than [Sleep Time].
• Speed Reference – The active speed command to the drive as selected by
drive logic and [Speed Ref x Sel].
• Start Command - A command generated by pressing the Start button on
the HIM, closing a digital input programmed for Start, Run, Run Forward
or Run Reverse.
Refer to Figure 22 .
Figure 22 - Sleep Wake Mode
Is Sleep-Wake
Working?
Have these conditions been met?
Is Required Input Closed?
(Stop, Enable, Run)
Did a Drive
Fault Occur?
Which Required Input
was Chosen?
Meet all Conditions!
Close Input
Reset Fault
Yes
Yes
Stop or Enable Run, Run Forward
or Run Reverse
Yes
Yes
Drive Running?
No
Direct Invert
No No
No
No
No
No
Issue a Start Command
(HIM, Network or TB)
Open & Close Input
Consult Factory
No
Consult Factory
Which Mode is Selected?
"Invert" or "Direct"
1. [Sleep-Wake Ref] must be set to the analog input that will control
"Start/Stop" functions.
2. [Sleep-Wake Mode] must = "1, Direct" (Enable) or "2, Invert (Enable)."
3. [Sleep Level] must be less than [Wake Level] in Direct mode (or
greater than [Wake Level] in "Invert" mode).
4. [Speed Ref x Sel] must be set to a speed reference source that will
control the drive. If [Sleep-Wake Ref] = [Speed Ref x Sel], the same
analog signal will control start/stop and speed reference.
5. At least one of the following must be programmed for [Digital Inx Sel]:
"Not Stop," "Enable," "Start," "Run," "Run Forward," "Run Reverse."
Is Analog Signal Greater
than or equal to [Wake Level]?
and for time period greater than
or equal to [Wake Time]
Yes Yes
Is Analog Signal Less
than or equal to [Wake Level]?
and for time period greater than
or equal to [Wake Time]
Increase Analog Input
Signal and wait for a time
period greater than or
equal to [Wake Time].
Decrease Analog Input
Signal and wait for a time
period greater than or
equal to [Wake Time].
Was a Stop Issued?
or Power Cycled?
