MDC-260 DEPOSITION CONTROLLER
COMPUTER INTERFACE 11-46
Code #35: Internal Command
Description: Instruction Code #32 is used by the software interface package and
is not designed for external interfacing.
Code #36: Not Supported
Description: Instruction Code #36 is not supported by the MDC-260. Attempting
to issue it to the controller will result in an “Invalid Instruction Code” error in the
message receipt.
Code #37: Not Supported
Description: Instruction Code #37 is not supported by the MDC-260. Attempting
to issue it to the controller will result in an “Invalid Instruction Code” error in the
message receipt.
Code #38: Remote Activation of Controller
Description: This instruction initiates a remote action. The possible actions are
shown in the following table:
Remote Action Code Description Action Trigger Type
0 Sound Alarm Action Momentary
1 Sound Alert Action Momentary
2 Sound Attention Action Momentary
3 Step From State Action One Shot
6 Clear Hold in State Action Continuous
5 Set Hold in State Action Continuous
6 Terminate Deposit Action One Shot
7 Halt Process Action One Shot
8 Switch Crystals One Shot
All the momentary actions trigger the action for a 100-millisecond period for each
message received. The one shot actions trigger the action once for each message
received. For example, sending one step from state message would cause the
controller to step into the next state one time. The continuous actions trigger that
action indefinitely. So the set hold in state action will cause the controller to hold
in the current state until the clear hold in state action is received and the exit state
condition is meet.
Format/Example:
• To initiate a Terminate Deposit action, transmit:
Header Interface
Address
Inst.
Code
Length Remote Action
Code
Checksum
Dec 255 254 1 38 1 6 210
