MDC-260 DEPOSITION CONTROLLER
COMPUTER INTERFACE 11-27
Code #20: Send Sensor Setup
Description: Instructs the controller to send the sensor setup parameter list for all
sensors. A description of the sensor parameter list is as follows:
Parameter Name Length
(bytes)
Decimal Pt.
Position
Values Units
Number of crystals 1 * 1 ...16 None
Shutter Relay Type 1 * 17 = Normally open,
18 = Normally closed,
19 = None
,
20 = Dual
None
Control 1 * 21 = Direct,
22 = BCD,
23 = Indiv,
24 = Manual None
Drive 1 * 25 = Up ,
26 = Down,
27 = Fast,
28 = Inline,
29 = Sngl Step,
30 = Dbl Step
None
Feedback Type 1 * 31 = Individual,
32 = BCD,
33 = Single Home,
34 = In Position,
35 = No Feedback None
Pocket Indexer Delay 1 * 0 ...99 Seconds
Total: 6 Data Bytes
There are two sensors with 6 bytes per sensor for a total of 12 bytes. All 12 bytes
are sent in the same message starting with sensor #1.
Format/Example:
• To instruct the controller to send the sensor setup parameter list, transmit:
Header Interface
Address
Instruction
Code
Length Checksum
Dec 255 254 1 20 0 235
Hex FF FE 01 14 00 EB
