MDC-260 DEPOSITION CONTROLLER
COMPUTER INTERFACE 11-34
Response:
• In addition to the normal transmission receipt, the controller will respond
with:
Header Interface
Address
Inst.
Code
Length Action #N
(1-8)
25 Data
Bytes
Checksum
Dec 255 254 1 26 26 5 (data) (checksum)
Hex FF FE 01 1A 1A 05 (data) (checksum)
(data): The 25 data bytes represent the configuration parameters the selected
Action.
(checksum):
The checksum from the instruction code through the last data byte.
The action type defines the action that will be taken when the condition is
evaluated as true. The following table contains the list of possible actions.
Action Name Action Type
No Action 1
Manual Power 2
Zero Thickness 3
Reset Process 4
Abort Process 5
Halt Process 6
Terminate Deposit 7
Hold In State 8
Step From State 9
Sound Attention 10
Sound Alert 11
Sound Alarm 12
Start Process 13
Select Process 1-8 14...21
Switch Crystals 22
Start Timer #1-8 23...30
Set Softnode #1-8 31...38
