MDC-260 DEPOSITION CONTROLLER
COMPUTER INTERFACE 11-25
Code #18: Send Source Setup
Description: Instructs the controller to send the source setup parameter list for all
sources. A description of the source parameter list for each source is as follows:
Parameter Name Length
(bytes)
Decimal Pt.
Position
Values Units
Number of Pockets 1 * 1 ...16 None
Shutter Relay Type 1 * 17 = Normally open,
18 = Normally closed,
19 = None None
Control 1 * 21 = Direct,
22 = BCD,
23 = Indiv,
24 = Manual None
Drive 1 * 25 = Up ,
26 = Down,
27 = Fast,
28 = Inline,
29 = Sngl Step,
30 = Dbl Step
None
Feedback Type 1 * 31 = Individual,
32 = BCD,
33 = Single Home,
34 = In Position,
35 = No Feedback
Pocket Indexer Delay 1 * 0 ...99 Seconds
Source Voltage Range 1 * 36 = 2.5V,
37 = 5.0V,
38 = 10V Volts
Shutter Delay 2 1 0 ...99 (LSB first) .1 sec
Total: 9 Data Bytes
There are two sources with 9 bytes per source for a total of 18 bytes. All 18 bytes
are sent in the same message starting with source #1.
