MDC-260 DEPOSITION CONTROLLER
COMPUTER INTERFACE 11-39
Code #29: Start Process
Description: Instructs the controller to start Process #N starting from Layer #Y.
Format/Example:
• To instruct the controller to start Process #6 starting from Layer #30,
transmit:
Header Interface
Address
Inst.
Code
Length Process #N
(1-10)
Layer #Y
(1-99)
Checksum
Dec 255 254 1 29 2 6 30
Hex FF FE 01 1D 02 06 1E
Response:
• The controller will respond with the normal transmission receipt.
Code #30: Send Run-Time Values
Description: Instructs the controller to send the run-time value list. A description
of the run-time value list follows the example.
Format/Example:
• To instruct the controller to send the run-time value list, transmit:
Header Interface
Address
Inst.
Code
Length Checksum
Dec 255 254 1 30 0 225
Hex FF FE 01 1E 00 E1
Response:
• In addition to the normal transmission receipt, the controller will respond
with:
Header Interface
Address
Inst.
Code
Length 103 Data
Bytes
Checksum
Dec 255 254 1 30 103 (data) (checksum)
Hex FF FE 01 1E 67 (data) (checksum)
(data): The 103 data bytes represent the run-time value list.
(checksum): The checksum from the instruction code through the last data byte.
