6036
WHEELS AND TIRES
3.17
Part Number
Qty.
Description
Item
No.
1
7092762
2
Tires & Wheel Assembly, Right Side (Includes items 2 thru 4)
2
8786514
1
Stem, Valve
3
7092533
1
Wheel, 24 x 9
4
8780027
1
Tire, 13.00 - 24, 10 Ply
5
7092772
2
Tire & Wheel Assembly, Left Side (Includes items 6 thru 8)
6
8786514
1
Stem, Valve
7
7092533
1
Wheel, 24 x 9
8
8780027
1
Tire, 13.00 - 24, 10 Ply
9
7084602
2
Tire & Wheel Assembly, Right Side (Optional) (Includes items 10 thru 12)
10
8786514
1
Stem, Valve
11
7078403
1
Wheel, 19.5 x 12.5
12
8780262
1
Tire, 15.00 - 19.5, 12 Ply
13
7084612
2
Tire & Wheel Assembly, Left Side (Optional) (Includes items 14 thru 16)
14
8786514
1
Stem, Valve
15
7078403
1
Wheel, 19.5 x 12.5
16
8780262
1
Tire, 15.00 - 19.5, 12 Ply
17
7092612
4
Tire & Wheel Assembly, Left or Right Side (Optional)
(Includes items 18 thru 20)
18
8786514
1
Stem, Valve
19
7092533
1
Wheel, 24 x 9
20
8780264
1
Tire 13.00R - 24, 14 Ply, Radial
The Following Rim Assembly is for S/N 1192 & Before
21
7083313
1
Rim Assembly - 4 Piece (Includes items 22 thru 24)
22
8786543
1
Flange
23
8786544
1
Locking Ring
24
8786545
1
O-Ring
Revised 11/97
