6036
8902125 1 Secondary Control Valve, 2 Section ( OBSOLETE - Order valve 8902151 with
two 8760419 (Item 34) plugs in work ports)
8902151 1 Secondary Control Valve, 3 Section (Includes Items 1 thru 33)
1 8033234 1 Section, Inlet
2 8033235 1 Section, Outlet
3 8033236 3 Section, Frame, Attachment Tilt & Auxiliary (Includes Items 4 thru 15)
4 See Kits 1 O-Ring
5 See Kits 2 O-Ring
6 See Kits 2 Wiper
7 See Kits 2 Plate, Seal
8 See Kits 2 Screw, Round Hd Machine
9 See Kits 1 Poppet, C.V.
10 See Kits 1 Spring
11 See Kits 2 Screw, Socket Hd Cap
12 See Kits 1 Cap, Spool
13 See Kits 1 End, Spool
14 See Kits 2 Seat, Spring
15 See Kits 1 Spring
16 8033165 2 Relief Valve, Port - Preset at 3250 ± 50 psi (Includes Items 19 thru 27)
17 8033412 1 Relief Valve, Main - Preset at 2850 ± 50 psi (Includes Items 19 thru 27)
18 8033150 2 Relief Valve, Port - Preset at 1200 ± 50 psi (Includes Items 19 thru 26
& 28)
19 See Kits 1 O-Ring
20 See Kits 1 Ring, Backup
21 See Kits 1 O-Ring
22 See Kits 1 Spring
23 See Kits 1 O-Ring
24 See Kits 1 Ring, Backup
25 See Kits 1 O-Ring
26 See Kits 2 O-Ring
27 See Kits 1 Spring (Used on Items 16 & 17 only)
28 See Kits 1 Spring (Used on Item 18 only)
29 See Kits 2 Rod, Tie (For 3 Section Valve)
30 See Kits 1 Rod, Tie (For 3 Section Valve)
31 See Kits 2 Nut, Special
32 See Kits 4 Nut, Special
33 8902512 2 Plug, Shutoff
34 8760419 2 Plug, Hex Hd, SAE 8 male str. thd. O-ring
KITS
35 8033155 AR Rebuild Kit, For individual service of Item 3 (Includes 4 of Item 4 &
listed quantities of Items 5 thru 15)
36 8902495 1 Seal & Spring Kit, Main & Port Relief Valve (Includes Items 19 thru 27)
37 8033219 1 Seal & Spring Kit, Port Relief (Includes Items 19 thru 26 & 28)
38 8902095 1 Tie Rod Kit (Includes Items 29 thru 32) For 3 Section Valves
Part Number Qty. Description
Item
No.
6.14
Revised 11/97
SECONDARY CONTROL VALVE
(S/N 9B0500 & AFTER)
