6036
5.6.2
Part Number Qty. Description
Item
No.
1 8902109 1 Valve, Steering Select
2 8902657 1 Valve, Brake Manifold (OBSOLETE - Order service valve
see "KITS" below to convert to declutch)
3 8902227 1 Valve, Priority
4 8902125 1 Valve, Secondary Control, 2 Section (OBSOLETE - Order Valve 8902151 with
two 8760419 plugs in work ports)
4A 8902151 1 Valve, Secondary Control, 3 Section
5 8760110 3 Connector, Straight, SAE 6-8, male JIC 37° x male str. thd. O-ring
6 8760313 1 Elbow, 90°, SAE 6-8, male JIC 37° x male str. thd. O-ring
7 8760113 2 Connector, Straight, SAE 4-4, male JIC 37° x male str. thd. O-ring
8 8760534 1 Tee, Male Run, SAE 4-4, male JIC 37° x male str. thd. O-ring
9 8760308 2 Elbow, 90°, SAE 8-10, male JIC 37° x male str. thd. O-ring
10 8760303 2 Elbow, 90°, SAE 8-8, male JIC 37° x male str. thd. O-ring
11 8760460 1 Reducer, SAE 8-6, male str. thd. O-ring x female internal O-ring boss
12 8760136 1 Connector, Straight, SAE 4-6, Male JIC 37° x male str. thd. O-ring
13 8760457 1 Tee, Male Branch, SAE 6-6, male JIC 37° x male str. thd. O-ring
14 7088692 1 Tube Assembly (S/N 9B0500 thru 0A0996)
7091592 1 Tube Assembly (S/N 0A0997 thru 0E1179)
15 2712292 1 Hose Assembly
16 6605182 1 Hose Assembly
17 8303703 2 Screw, Hex Hd Cap, 1/4-20 x 2-1/2
18 8307106 2 Washer, Flat, 5/16
19 8305626 4 Locknut, 5/16-18
20 8304631 4 Screw, Socket Hd Cap, #10-24 x 2
21 8304608 2 Screw, Socket Hd Cap, 5/16-18 x 1-1/2
22 8303675 3 Screw, Socket Hd Cap, 3/8-16 x 1-1/4
23 8303757 2 Screw, Socket Hd Cap, 5/16-18 x 2-1/2
24 8278008 4 Mount, Rubber
25 7098293 1 Plate, Valve Mounting
26 8902111 1 Body, Steer Select Valve
27 8304042 4 Bolt, Carriage, 3/8-16 x 2
28 8310070 4 Retainer, Bolt 3/8
29 7057141 4 Washer, Rebound
30 8307005 4 Lockwasher, 3/8
31 8305008 4 Nut, Hex, 3/8-16
32 8305645 3 Locknut, 3/8-16
33 8305624 2 Locknut, 1/4-20
34 8760307 1 Elbow, 45° SAE #8 - JIC #8
KITS
35 7092552 1 Kit, Declutch Conversion (Refer to page 5.52 for kit parts)
Revised 11/97
VALVE PLATE ASSEMBLY
(S/N 9B0500 THRU S/N 0E1179)
