Boom extend cylinder 6.5, Important – SkyTrak 6036 Parts Manual User Manual
Page 207
6036
BOOM EXTEND CYLINDER
6.5
Part Number
Qty.
Description
Item
No.
2711693
1
Cylinder, Boom Extend/Retract - TJB (Icludes Items 1 thru 18)
1
8032731
1
Rod
2
See Kits
1
Wiper
3
See Kits
1
Seal, Rod
4
See Kits
1
Seal, Piston
5
8032734
1
Piston
6
See Kits
1
Setscrew, Nylon
7
See Kits
1
Setscrew
8
See Kits
1
O-Ring
9
8032736
1
Tube, Stop
10
See Kits
1
O-Ring
11
See Kits
1
Ring, Backup
12
8032732
1
Gland
13
NSS
1
Tube Cylinder
14
8902212
1
Valve, Counterbalance w/o TLC (See Kits)
15
8032737
1
Valve, Counterbalance w/TLC Only (See Kits)
16
8032738
2
Plug
17
See Kits
1
Seal, Step
18
See Kits
1
O-Ring
KITS
19
8205659
1
Seal Kit, Boom Extend/Retract Cylinder (Includes Items 2, 3, 4, 6, 7,
8, 10, 11, 17 & 18)
20
8205656
2
Seal Kit, Counterbalance & Pilot Check Valves (Includes 3 O-Rings & 3 Backup Rings)
21
8035246
1
Seal Kit, Gland Static Seal (Consists of 1 O-Ring & 1 Backup Ring)
Part Number
Qty.
Description
Item
No.
2711693
1
Cylinder, Boom Extend/Retract - BHE (Includes Items 1 thru 20)
1
8033119
1
Rod
2
See Kits
1
Wiper
3
See Kits
1
Seal
4
See Kits
1
O-Ring
5
8033115
1
Head
6
See Kits
1
Ring, Backup
7
See Kits
1
O-Ring
8
8033122
1
Spacer
9
8033123
1
Ring, Snap
10
See Kits
2
Ring, Backup
11
See Kits
1
O-Ring
12
8033128
1
Piston
13
See Kits
1
Seal/Expander Assembly
14
See Kits
1
Bearing
15
8033129
1
Screw, Hex Hd Cap
16
NSS
1
Barrel
17
See Kits
2
O-Ring
18
8033131
2
Plug
19
8902473
1
Valve, Counterbalance
20
8032737
1
Valve, Pilot Check
KITS
21
8205667
1
Seal Kit, Boom Extend/Retract Cylinder (Includes Items 2, 3, 4, 6, 7, 10,
11, 13, 14 & 17)
22
8205656
2
Seal Kit, Counterbalance & Pilot Check Valve (Includes 3 O-Rings & 3 Backup Rings)
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
123456789012345678901234567890121234567890123456789012345678901
IMPORTANT !
Before ordering internal service parts, you must first identify the cylinder by the
manufacturer's stamping (see illustrations). The BHE cylinders are no longer
available as individual complete assemblies. You must replace individual BHE
cylinders with a pair of the same TJB cylinders.
Revised 9/94
