6036
Part Number Qty. Description
Item
No.
OPERATOR'S CAB - CLOSED (OPTIONAL)
2.2
1 See Page 2.1 1 Cab Assembly
2 7099324 1 Cab, Enclosed (Includes Items 3 thru 49 on this page and all parts on page 2.11)
3 8307207 1 Washer, Flat, 5/8
4 8033079 2 Window, Wing
5 8033081 1 Window, Skylight
6 8033092 4 Screw, Socket Hd, #10-24 x 3/4
7 8033072 1 Seal, Rubber, 120 in.
8 8307113 1 Washer, Flat, 7/16
9 8305647 1 Locknut, 7/16-14l
10 8307206 AR Washer, Flat, 1/2
11 8346010 1 Bolt, Striker
12 8307003 4 Lockwasher, #10
13 8307201 4 Washer, Flat, 3/16
14 8033085 2 Hinge, Spring
15 8033084 1 Window, Rear
16 8033086 8 Nut, Well
17 8033087 4 Washer, Nylon
18 8033088 8 Screw, Phillips Hd, #10-32 x 3/4
19 8033044 1 Window Hold Slide Assembly, w/Hardware
20 8585135 3 Tape, Butyl, 1/4" square x 15' Roll (See Kits)
21 8303540 2 Screw, Hex Hd Cap,1/4-20 x 1
22 8342413 1 Strap
23 8033090 1 Bracket, Door Mounting
24 8305601 6 Locknut, 1/4-20
25 8303982 4 Screw, Self Tapping, 1/4-20 x 3/4
26 8346011 1 Panel, Rear Foam
27 8585138 1 Weldment, Latch Bracket
28 8580315 1 Plug, Hole
29 8033479 1 Window, Front
30 8033076 1 Wire Assembly, Fan
31 8033078 1 Fan, Defroster
32 8033077 2 Connector, Wire
33 8033094 1 Bracket, Fan
34 8585139 2 Washer, Flat Plastic, 3/8
35 8307204 2 Washer, Flat, 3/8
36 8580115 1 Knob
37 8303776 2 Screw, Hex Hd Cap, 1/4-20 x 1/2
38 8303540 2 Screw, Hex Hd Cap, 1/4-20 x 1
39 8585134 AR Sealant, Urethane, 10 oz Cartridge (Location Shown Only) (See Kits)
40 8307002 2 Lockwasher, 1/4
41 8346009 1 Window, Right Side Sliding (Includes Items 43 thru 49)
42 8033833 1 Glass Assembly, Front
43 8033834 1 Glass Asembly, Rear
44 8033835 1 Frame Assembly
45 8033836 1 Trim Stop, Front
46 8033837 1 Trim Stop, Rear
47 8033838 2 Rubber, Flkd
48 8033839 1 Rubber, Flkd
49 8033840 1 Rubber, Flkd
50 8033082 1 Window, Right Side (Optional)
KITS
51 8585133 1 Window Glue Kit (Includes Items 20, 39, four Setting Blocks and
one Set of Installation Instructions)
52 7111332 1 Door Strap Kit (For Gas Spring Replacement on Older Machines)
(Includes Items 22 and 25)
Revised 11/97
