SkyTrak 6036 Parts Manual - Manual (Page 157)

6036
5.4.2
Part Number Qty. Description
Item
No.
Revised 11/97
ATTACHMENT TILT, SLAVE & FRAME TILT CIRCUITS
(S/N 6036-1317 & AFTER)
1 2711882 2 Hose Assembly, Attachment Tilt Cylinder
2 7082673 1 Tube Assembly, Attachment Tilt Cylinder
3 7084673 1 Tube Assembly, Attachment Tilt Cylinder
4 8760045 2 Union, Bulkhead, Straight, SAE 8 - male JIC 37°
5 2709372 1 Hose Assembly, Slave Cylinder Retract
6 2712322 1 Hose Assembly, Slave Cylinder Extend
7 2712112 1 Hose Assembly, Slave Tube
8 6604782 2 Hose Assembly, Frame Tilt Cylinder
9 8760110 3 Connector, Straight, SAE 6-8 - male JIC 37° x male str. thd. O-ring
10 8770031 2 Connector, Straight, SAE 4-4 - male JIC 37° x male str. thd. O-ring
11 8760107 2 Connector, Straight, SAE 8-8 - male JIC 37° x male str. thd. O-ring
12 8760268 2 Elbow, 90° SAE 6-6 - male JIC 37° x female JIC 37° swivel
13 8760458 1 Reducer, Tube End, SAE 8-6 - JIC 37°
14 8760407 1 Nut, SAE 8 - JIC 37°
15 8760303 1 Elbow, 90° SAE 8-8 - male JIC 37° x male str. thd. O-ring
16 8760510 2 Tee, Male Run, SAE 8-8 - male JIC 37° x male str. thd O-ring
17 8769139 1 Clamp Set, Twin (2 halves, 3/4 ID)
18 8769128 2 Plate, Cover
19 8303752 1 Screw, Hex Hd Cap, 5/16-18 x 3
20 8305626 1 Locknut, 5/16-18
21 2711912 1 Hose Assembly, Slave to Tube
22 8769122 3 Clamp Set, Twin Tube (2 halves, 5/8 ID)
23 8769123 3 Plate, Clamp Top
24 8303739 3 Screw, Hex Hd Cap, 5/16-18 x 1-1/4
25 8769154 2 Clamp Set, (2 halves, 5/8 ID)
26 8769153 2 Cover, Clamp
27 8303743 4 Screw, Hex Hd Cap, 1/4-20 x 1-1/2
