Page 209
6036
ATTACHMENT TILT CYLINDER
15
1
2
13
SEE
KITS
6
7
9
10
3
4
5
6
7
8
9
10
11
14
12
16
17
2711703
1
Cylinder, Attachment Tilt (Includes Items 1 thru 13)
1
NSS
1
Tube, Cylinder
2
8032702
1
Nut
3
See Kits
1
Seal, Piston
4
8032746
1
Piston
5
See Kits
1
O-Ring
6
See Kits
1
O-Ring
7
See Kits
1
Ring, Backup
8
8032704
1
Gland
9
See Kits
1
Seal, Rod
10
See Kits
1
Wiper
11
8032747
1
Rod
12
7089722
2
Bushing
13
8902247
1
Valve, Counterbalance (See Kits)
14
8520013
1
Fitting, Grease
15
8520021
1
Fitting, Grease, 90°
KITS
16
8032707
1
Seal Kit, Attachment Tilt Cylinder (Includes Items 3, 5, 6, 7, 9 & 10)
17
8205656
1
Seal Kit, Counterbalance Valve (Includes 3 O-Rings & 3 Backup Rings)
Part Number
Qty.
Description
Item
No.
6.7
PA0613
PA0613
PF0760
Revised 9/94
