SkyTrak 6036 Parts Manual - Manual (Page 173)

6036
5.6.3
Part Number Qty. Description
Item
No.
1 8902109 1 Valve, Steering Select
2 8902659 1 Valve, Brake Manifold
3 8902227 1 Valve Priority
4 8902125 1 Valve, Secondary Control, 2 Section (OBSOLETE - Order Valve 8902151 with
two 8760419 plugs in work ports)
5 8760110 3 Connector, Straight, SAE 6-8, male JIC 37° x male str. thd. O-ring
6 8760313 1 Elbow, 90°, SAE 6-8, male JIC 37° x male str. thd. O-ring
7 8760113 3 Connector, Straight, SAE 4-4, male JIC 37° x male str. thd. O-ring
8 8760534 1 Tee, Run, SAE 4-4, male JIC 37° x male str. thd. O-ring
9 8760308 2 Elbow, 90°, SAE 8-10, male JIC 37° x male str. thd. O-ring
10 8760303 2 Elbow, 90°, SAE 8-8, male JIC 37° x male str. thd. O-ring
11 8760457 1 Tee, Male Branch, SAE 8-8, male JIC 37° x male str. thd. O-ring
12 8760460 1 Reducer, SAE 8-6, male str. thd. O-ring x female internal O-ring boss
13 8760136 1 Connector, Straight, SAE 4-6, male JIC 37° x male str. thd. O-ring
14 8305624 2 Locknut, 1/4-20
15 8303728 2 Screw, Hex Hd Cap, 1/4-20 x 2-3/4
16 7091592 1 Tube Assembly
17 2712292 1 Hose Assembly
18 6605182 1 Hose Assembly
19 8307106 2 Washer, Flat, 5/16
20 8305626 4 Locknut, 5/16-18
21 8304631 4 Screw, Socket Hd Cap, #10-24 x 2
22 8304608 2 Screw, Socket Hd Cap, 5/16-18 x 1-1/2
23 8303675 3 Screw, Socket Hd Cap, 3/8-16 x 1-1/4
24 8303757 2 Screw, Socket Hd Cap, 5/16-18 x 2-1/2
25 8278008 4 Mount, Rubber
26 7098293 1 Plate, Valve Mounting
27 8902111 1 Body, Steer Select Valve
28 8304042 4 Bolt, Carriage, 3/8-16 x 2
29 8310070 4 Retainer, Bolt 3/8
30 7057141 4 Washer, Rebound
31 8307005 4 Lockwasher, 3/8
32 8305008 4 Nut, Hex, 3/8-16
33 8305645 3 Locknut, 3/8-16
34 8760307 1 Elbow, 45°, SAE 8-8, male JIC 37° x male str. thd. O-ring
35 8520030 1 Filter, Inline Fitting (S/N 6036-5532 & After)
Revised 11/97
VALVE PLATE ASSEMBLY
(S/N 0E1180 & AFTER)
